CNC multi-layer Cutting Machine

CNC  multi-layer Cutting Machine

● The cutting platform automatic compensation system of the CNC cutting machine automatically adjusts the depth of the lower knife during cutting, which overcomes the difficulty of adjusting the platform before and after the CNC cutting machine leaves the factory.
● It adopts four-axis linkage CNC cutting technology, which represents the development direction of flexible machining. Imported linear guide rail combined with a fully digital servo motor is used as the motion control structure in the XY direction. The Z direction uses a fully digital servo motor to control the cutting head for rapid up and down depth positioning, and the T direction uses a high-precision fully digital servo motor to control the cutting knife to automatically identify the line attribute trajectory. The transmission part uses imported JAPAN high-speed all-digital servo motors.
● When the CNC cutting machine is working, the four axes of X, Y, Z and T must be started at the same time and run physical interpolation. It has associativity, adaptability, expandability, ease of use, high performance, high precision and strong openness, etc. Advantages, the operation interface is simple and easy to learn, and the stability and operability have reached the leading technical level at home and abroad.

Main Feature

● Composed of belt conveyor drive and fully automatic movement module
● The CNC cutting machine adds a T-axis device on the basis of the original three-axis linkage. This device enables the cutting knife to automatically recognize the line attribute track during the cutting process. When cutting flexible materials, it can carry out complex graphic design and ordinary cutting punches cannot be realized and cut. The high-precision cutting operation that cannot be made makes the finished product smooth and beautiful, and it controls the high-speed up and down movement of the cutting knife.
● The new technology of automatic switching device between knife and punching means that it will automatically switch to knife cutting after punching, and the knife pressure data of various flexible materials can be set arbitrarily, so that all drawing and cutting work can be completed at one time.
● The CNC cutting machine has the function of positioning and automatically identifying the line attribute track, which can greatly improve the effect and accuracy of cutting flexible materials.
●Reinforced welding frame, large gantry precision milling machine processing, annealing treatment to eliminate stress and keep the frame from deformation。
● High dynamic and large inertia servo motor and high-precision rack and linear track, with high dynamic response performance and high load capacity.
● The working platform adopts a crawler conveyor design, high temperature resistance, corrosion resistance, good toughness, no deformation, stable and fast feeding speed.
● The working platform adopts a segmented vacuum adsorption and smoke exhaust device, which has strong adsorption and good smoke exhaust effect.
●The use of large inertia servo motor, abandoning the traditional stepper motor, faster, higher efficiency, and the machine runs more smoothly

Standard Configurations

Technical Parameter

List of main components
